SiRON T380-13-C 8-Port Unmanaged 100Mbps Industrial Switch
Giá: Liên hệ
Features
● Provide 8 10/100/1000Mbps electrical ports, EMC industrial level 4 electromagnetic anti-interference.
● Support dual power supply redundancy backup, reverse protection input power supply.
● Support IP40 protection class, fanless design, aluminum alloy metal housing, DIN rail mounting/wall mounting.
● Support wide temperature design -40℃ ~ 85℃ to meet harsh environment application requirements.
Chi tiết sản phẩm
Selection reference
| Model | T380-13-C |
| Electrical interface | 8 |
| Speed | Gibagit |
| Power source | DC12-52V |
| Port description | 8×10/100/1000Mbps RJ45port |
Specification
| Rj45port | 10/100/1000BaseT (X)automatic detection;Ful/half-duplex MDI/MDI-X adaptive | ||||
| Network protocol | EEE802.3-CSMA/CD;IEEE802.3i-10Base-T; EEE802.3u-100Base-TX/FX;IEEE802.3x-Flow Control; EEE802.3z-1000Base-X;IEEE802.3ab-1000Base-T; |
||||
| Access terminal | Phoenix Terminal | ||||
| Mean time between failures | 300,000 hours | ||||
| Switch properties |
Backplane bandwidth | 16Gbps | Mechanical characteristic |
Shell | P40 protection grade,metal casing |
| Application level | Two layers | Install | DIN card rail type,wall-mounted type | ||
| Packet forwarding rate of the system | 11.904Mpps | Heat dissipation mode | Install natural cooling,fanless | ||
| MAC table | 8K | Working environment |
Operating temperature | -40~85°℃(-40~185°F) | |
| Packet buffer | 2M | Storage temperature | -40~85℃(-40~185°F) | ||
| Delay time | <3μs | Relative humidity | 5%~95%(without condensation) | ||
| Switching mode | Storage -Forwarding | LED index | Power indicator light | PWR | |
| Overall power consumption | <3W | Interface indicator |  Electrical interface(Link/ACT) |
||
| Industry standard | EMI: FCC Part 15 Subpart B Class A,EN 55022 Class A EMS: EC(EN)61000-4-2(ESD):±8kV(contact),±15kV(air) EC(EN)61000-4-3(RS):10V/m(80～1000MHz) IEC(EN)61000-4-4(EFT):Power Port:±4kV;Data Port:±2kV EC(EN)61000-4-5(Surge):Power Port:±2kV/DM,±4kV/CM;Data Port:±2kV IEC61000-4-6(CS):10V(150kHz~80MHz)/IEC(EN)61000-4-16(CM EM):30V cont.300V,1s EC 60068-2-27(Shock)/IEC 60068-2-32(Freefall)/IEC 60068-2-6(Vibration) |
