SiRON K011-8 Series Background Suppression Laser Sensor
Giá: Liên hệ
Features:
*Laser light source, small spot to achieve accurate detection of small objects;
*With background suppression function, detection is not affected by the workpiece material and background color;
*Small light spot or linear spot can be selected according to application requirements;
*Strong anti-interference, high stability.
*With background suppression function, detection is not affected by the workpiece material and background color;
*Small light spot or linear spot can be selected according to application requirements;
*Strong anti-interference, high stability.
Chi tiết sản phẩm
Product Description
About selection
Selection example: K011-8 indicates the K011 series, serial numbers 8, with NPN output.
K011-8P indicates the K011 series, serial numbers 8, with PNP output.
Specifications
| Name | Laser sensor |
| Model | K011-8 K011-8P |
| Output mode | NPN PNP |
| Appearance |   |
| Types of | Diffuse reflection |
| Set distance | 30-400mm |
| Stable detection distance | 10 – 300mm(Background suppression type) |
| Spot size | φ1X2mm |
| Black and white error | 3%(distance 160mm) |
| Acceptanassignment | Less than 3% of the rated detection distance |
| Current consumption | ≤30mA |
| Light source(wavelength) | Laser(655nm),JIS/IEC CLASS1,FDA CLASSI below 4.5mW |
| Control output | Load power supply voltage: DC 26.4V or less,Load current:100mA or less,
Leakage current: 10μA or less,Open collector output(NPN/PNP output varies by type) Toggle type: ON when the white wire is not exposed to light / ON when the white wire is exposed to light and the blue wire is shielded from light |
| Output residual voltage | Residual voltage below 1V (load current less than 10mA) Residual voltage below 2V (load current less than 10 to 100mA) |
| Supply voltage | DC 12~24V±10% fluctuation (P-P) below 10% |
| Response time | Action·Reset: ≤0.5ms |
| Ambient temperature | Operating temperature: -25 to +55℃; Storage time: -40℃ to +70℃(but no freezing or condensation) |
| Ambient humidity | When in operation: Humidity 35-85%RH; Storage time: -35 to 95%RH(but no freezing or condensation) |
| Proteclion circuit | Power reverse connection protection/load short circuit protection/mutual interference prevention function/output reverse connection protection |
| Class of protection | IP64 |
| Line length | 2m |
| Material | Shell: Polybutylene terephthalate; Display section: Polyester composite rubber; Lens section: Polyester composite rubber |
